- Material: Polyester
- Features: Air Tight Inner Core, Encapsulated Wire Helix, Smooth Inner Core, Thick Blanket of Fiberglass Insulation, Tough Reinforced Gray Polyester Jacket, Light Weight Compact Carton
- Flexible Duct Item: Insulated Flexible Duct
- Max. Pressure: 10"WC
- Insulation Value: R 6.0
Insulated Flexible Duct, Insulation Value R 6.0, UPC Number 76, Flexible Duct Inside Dia. 14 In., Flexible Duct Wall Thickness 2 In., Vapor Transmission 0.60, Material Polyester, Flexible Duct Length 25 ft., Max. Air Flow 5000 fpm, Max. Pressure 10 In.WC, Max. Temp. 180F, Compressed Size 26 In., Low Temp. Deg. -20 Degrees F, For Use With Heating and Cooling Systems
Specification:
- Material: Polyester
- Features: Air Tight Inner Core, Encapsulated Wire Helix, Smooth Inner Core, Thick Blanket of Fiberglass Insulation, Tough Reinforced Gray Polyester Jacket, Light Weight Compact Carton
- Flexible Duct Item: Insulated Flexible Duct
- Max. Pressure: 10"WC
- Insulation Value: R 6.0
- Vapor Transmission: 0.60
- Includes: (2) Ply Gray Polyester Vapor Barrier
- Flexible Duct Length: 25 ft.
- Item: Insulated Flexible Duct
- Max. Temp.: 180F
- Standards: UL181, NFPA 90A and 90B, IMC, IRC, UMC 10-1 (ICC ES Report No. ESR-1268), HUD, Cities of Chicago, New York, San Francisco, County of Dade (Florida), California State Fire Marshall
- Flexible Duct Wall Thickness: 2"
- Flexible Duct Inside Dia.: 14"
- Max. Air Flow: 5000 fpm
- UPC Number: 76
- Low Temp. Deg.: -20 Degrees F
- For Use With: Heating and Cooling Systems
- Compressed Size: 26"
